Construction:
- Mounting plate made from galvanized steel.
- Protective shroud manufactured from drawn steel rods, compliant with UNI 10615:1997 regulations.
- High efficiency, low noise, backward curved blade impeller made from galvanized steel sheet, statically and dynamically balanced statically and dynamically according to the ISO 1940 standard.
- Asynchronous single- or three-phase motor, CE marked, with IP55 protection and Class F insulation, manufactured according to the following international standards: IEC 600034, IEC 60072, EMC 2014/30/UE, LVD 2014/35/UE. Suitable for S1 Service (continuous operation at constant load).
- Upper cover made from ABS plastic, featuring cooling slots for the motor.
- Outer deflector made from high-strength ABS.
Accessories:
- Backdraught gravity shutters(TS)
- Silencer(GR)
- Mounting plate for corrugated roofs (BA)
- Inlet protection guard(RA)
- Service switch
- Acoustically insulated support base(PB)
Special versions:
- AT version: Horizontal discharge version, suitable for conveying hot air in continuous service.(up to 200°C).
-
-
- (See: High temperature fans)
-
-
- HT version: High temperature, horizontal discharge version for emregency smoke extraction in case of fire.
-
-
- (See: Smoke extraction fans)
-
-
- ATEX version: ATEX certified version, compliant with directives 94/9/CE and 2014/34/UE.
-
-
- (See: ATEX Fans)
-
-
